Soldering Machine

• Connectivity Options
• Vibrating plate feeding

• Control System
• Other, Touch Screen Control

• Features
• Stripping, Cutting, Soldering, Vibrating plate feeding type-c connector

• Frequency
• 50/60Hz

• Machine Type
• Soldering Machine

• Model No
• SR-160

• Operating Type
• Automatic

• Power
• 1000W

• Power Rating
• 1000W

• Power Source
• Other, Electric

• Pressure
• 0.5-0.8MPa

• Product Type
• Other, Automatic Data Cable Soldering Machine

• Technology
• Other, Soldering Automation

• Usage & Applications
• Type-C, Micro, Lightning, Data Cable Soldering

• Voltage
• AC220V 50/60Hz

• Weight (kg)
• 100

• Color
• Grey/White

• Control System
• Other, Constant temperature (area)

• Dimension (L*W*H)
• 0.96x0.62x1.1M

• Drive
• Electric motor

• Machine Type
• Soldering Machine

• Model No
• SR-230

• Motor Power
• 0.2Kw

• Operating Type
• Automatic

• Power
• 0.5Kw

• Power Source
• Other, Electric

• Pressure
• 0.4-0.8Mpa

• Product Type
• Other, Automatic USB Soldering Machine

• Production Capacity
• 600-900Pcs/H

• Technology
• Other, Precision soldering

• Usage & Applications
• USB cable soldering

• Voltage
• 220V

• Weight (kg)
• 150Kg

• Accuracy
• +0.02mm repeat accuracy

• Control System
• Other, Direct coordinate programming, teaching

• Dimension (L*W*H)
• 650*550*850 mm

• Drive
• Stepper

• Features
• 4 axle + tin solder, Program recording capability: 1000, Min tin length: 0.01 mm, Solder wire dia: 0.3-1.2mm

• Frame Type
• Desktop

• Frequency
• 50HZ

• Machine Type
• Dual Platform Desktop Robot

• Motor Power
• Stepper motor

• Operating Temperature
• 0-40C

• Operating Type
• Other, Desktop, automatic

• Power Source
• Other, 220V AC/50HZ

• Pressure
• 0.4-0.8MPa, clean and dry

• Product Type
• Other, LED Light Automatic Soldering Machine

• Production Capacity
• One station

• Technology
• Other, High frequency eddy current heating

• Usage & Applications
• LED light soldering, PCB assembly

• Voltage
• 220V AC

• Weight (kg)
• 65 kg

• Color
• Silver/Blue

• Control System
• Other, Digital Display

• Dimension (L*W*H)
• 45*32*25cm

• Frequency
• 50-60Hz

• Machine Type
• HDMI Cable Soldering Machine

• Model No
• SR-MC101

• Operating Temperature
• 10-60C

• Power
• 1.8KW

• Production Capacity
• 1000-1300pcs/H

• Voltage
• 220V AC 50-60HZ

• Weight (kg)
• 15

• Color
• Industrial blue

• Connectivity Options
• HDMI compatible

• Control System
• Other, Digital timer

• Cooling System
• Air-cooled

• Dimension (L*W*H)
• 45*32*25cm

• Drive
• Electric/Pneumatic

• Frame Type
• Industrial compact

• Frequency
• 50-60HZ

• Machine Type
• Semi-automatic soldering

• Noise Level
• Low noise

• Operating Temperature
• 10-60C

• Operating Type
• Other, Manual and pneumatic

• Power
• 1.8KW

• Power Rating
• 1.8KW

• Power Source
• Other, 220V AC 50-60HZ

• Pressure
• 0.4-0.5mpa

• Production Capacity
• 1000-1300 pcs/H

• Surface Treatment
• Other, Powder coated

• Voltage
• 220V AC

• Weight (kg)
• 15KG

• Accuracy
• Repeat Precision 0.02mm

• Color
• Silver/Gray

• Control System
• Other, Dedicated control system

• Dimension (L*W*H)
• 750*580*850mm

• Drive
• Screw drive

• Features
• 5 axes + tin solder

• Machine Type
• ST380C

• Model No
• ST380C

• Operating Temperature
• 0-40C

• Operating Type
• Automatic

• Product Type
• Other, Intelligent Soldering Machine

• Technology
• Other, Torque servo + screw

• Usage & Applications
• PCB Soldering, Automation

• Weight (kg)
• 95kg

• Accuracy
• 0.02 mm

• Color
• White

• Connectivity Options
• USB, Ethernet

• Control System
• Other, Microcontroller Based

• Cooling System
• Air Cooling

• Dimension (L*W*H)
• 520 x 600 x 800 mm

• Drive
• Stepper Motor

• Features
• Intelligent Control, High Precision, User Friendly Interface

• Frame Type
• Aluminum Frame

• Frequency
• 50/60 Hz

• Lubricating System
• Automatic

• Machine Type
• Tabletop

• Model No
• ISR-6A-2024

• Motor Power
• 60 W

• Noise Level
• < 65 dB

• Operating Temperature
• 0-40C

• Operating Type
• Automatic

• Power
• 150 W

• Power Rating
• 150 W

• Power Source
• Other, Electric

• Pressure
• 0.5-0.7 MPa

• Product Type
• Other, Soldering Robot

• Production Capacity
• 500 pcs/hour

• Surface Treatment
• Other, Powder Coated

• Technology
• Other, Automated Soldering

• Usage & Applications
• PCB Assembly, Electronics Manufacturing

• Voltage
• 220 V

• Weight (kg)
• 38 kg

• Accuracy
• Feeding precision 0.2mm

• Color
• Standard industrial

• Control System
• PLC

• Cooling System
• Integrated

• Dimension (L*W*H)
• 900*900*1800mm

• Features
• High-precision, dual station

• Frame Type
• Enclosed cabinet

• Frequency
• 50Hz

• Machine Type
• Laser Soldering Machine

• Model No
• SR-VS420

• Motor Power
• Servo motor

• Noise Level
• Low noise

• Operating Temperature
• 100C ~ 480C

• Operating Type
• Automatic

• Power
• 150W

• Production Capacity
• 2 working stations

• Surface Treatment
• Other, Powder coated

• Technology
• Other, CCD vision positioning

• Usage & Applications
• PCB, microelectronics

• Voltage
• 220V AC

• Weight (kg)
• 400kg

• Accuracy
• +2C

• Color
• Industrial metallic gray

• Control System
• Other, Touch Screen

• Cooling System
• Passive cooling

• Dimension (L*W*H)
• 52*50*77cm

• Drive
• Motor drive (pneumatic option)

• Features
• Automatic tin feeder

• Frame Type
• Compact upright

• Frequency
• 50/60Hz

• Lubricating System
• Maintenance free

• Machine Type
• Semi auto soldering

• Model No
• SR-ST150(motor)

• Motor Power
• 200W motor

• Noise Level
• Low

• Operating Temperature
• 50-600C

• Operating Type
• Other, Semi-automatic

• Power
• 200W

• Power Source
• Other, Electric motor driven

• Pressure
• 0.4-0.8MPa, clean and dry

• Production Capacity
• Multiple welding point

• Surface Treatment
• Other, Powder coated frame

• Technology
• Other, Motor drive soldering

• Usage & Applications
• Universal Soldering, USB-A, Micro, Type-C, lightning, connector etc

• Voltage
• AC220V/110V

• Weight (kg)
• 18

• Accuracy
• +3 C

• Dimension (L*W*H)
• 810mm (L) x720mm (W) x1300mm (H)

• Model No
• MC302

• Operating Temperature
• 0-40 C

• Pressure
• 0.02-0.8MPa adjustable

• Production Capacity
• 400-600pcs/hour

• Weight (kg)
• 130Kg

• Accuracy
• 3C

• Color
• Light Grey

• Control System
• Other, Digital Display

• Dimension (L*W*H)
• 400mm (L) x 450mm (W) x 510mm (H)

• Machine Type
• Precision Soldering

• Model No
• MC301

• Operating Temperature
• 0-40C

• Power Source
• Other, AC 220V

• Pressure
• 0.02-0.8MPa adjustable

• Technology
• Other, Pulse Soldering

• Weight (kg)
• 85Kg

• Accuracy
• High Precision

• Color
• Grey

• Control System
• Other, Digital Controller

• Cooling System
• Air Cooled

• Dimension (L*W*H)
• 400mm x 450mm x 510mm

• Drive
• Pneumatic Drive

• Frame Type
• Enclosed

• Frequency
• 50/60Hz

• Machine Type
• Pulse Soldering Machine

• Model No
• MC501

• Noise Level
• Low Noise

• Operating Temperature
• 0-40C

• Operating Type
• Automatic

• Power Source
• Other, AC Electric

• Pressure
• 0.02-0.8Mpa, adjustable

• Production Capacity
• 400-700 pcs/hour

• Surface Treatment
• Other, Powder Coated

• Technology
• Other, Precision Pulse

• Usage & Applications
• Electronic Soldering

• Voltage
• 220V

• Weight (kg)
• 135Kg

• Accuracy
• +2C Temperature Accuracy

• Connectivity Options
• PLC External Port

• Control System
• PLC

• Cooling System
• Passive Air Cooling

• Dimension (L*W*H)
• 520*495*775MM

• Drive
• Pneumatic/Electric

• Features
• Adjustable Soldering Time & Tin Feeder

• Frame Type
• Robust Metal Structure

• Lubricating System
• Self-contained grease points

• Machine Type
• Soldering Machine

• Model No
• SR-150T

• Noise Level
• Low Operation Sound

• Operating Temperature
• 50-600C

• Operating Type
• Other, Semi-Automatic

• Power
• 200W

• Power Rating
• 200W

• Power Source
• Other, Pneumatic or Electric drive

• Pressure
• 0.4 - 0.8MPa, clean and dry

• Product Type
• Other, Semi Automatic Soldering Machine

• Production Capacity
• Multiple Soldering Points per cycle

• Technology
• Other, Touch Screen PLC Control

• Usage & Applications
• PCB/Component Soldering

• Voltage
• AC220V

• Weight (kg)
• 15kg

• Accuracy
• 2 C (temperature control)

• Color
• Light grey (as shown)

• Connectivity Options
• Manual loading, pneumatic drive (motor option)

• Control System
• Other, Touch Screen Interface

• Cooling System
• Air cooled

• Dimension (L*W*H)
• 52*50*77 cm

• Drive
• Pneumatic (standard), Motor (optional)

• Features
• Universal soldering, adjustable tin feeder, multi-connector capability

• Frame Type
• Rigid steel frame

• Frequency
• 50/60 Hz

• Machine Type
• Universal Soldering for Connectors

• Model No
• SR-ST150

• Motor Power
• Optional motor drive

• Noise Level
• < 70 dB

• Operating Temperature
• 50 - 600 C

• Operating Type
• Other, Semi-automatic

• Power
• 200 W

• Power Rating
• 200 W

• Power Source
• Other, AC220V / 110V, 50/60Hz

• Pressure
• 0.4~0.8 MPa, clean and dry

• Product Type
• Other, Universal Soldering Machine

• Production Capacity
• Multiple welding points per cycle

• Technology
• Other, Semi-Automatic Soldering

• Usage & Applications
• USB Micro/Type-C/Lightning/Universal Soldering

• Voltage
• AC220V / 110V

• Weight (kg)
• 18 kg

• Accuracy
• High precision soldering

• Color
• Silver

• Connectivity Options
• Multiple plug types (AU, UK, EU, US, BR)

• Control System
• Other, Manual with pneumatic assistance

• Cooling System
• Natural air cooling

• Dimension (L*W*H)
• 400mm*400mm*450mm

• Drive
• Pneumatic / Electric

• Features
• Compact, energy efficient, user friendly

• Frame Type
• Rigid metal frame

• Frequency
• 50/60Hz

• Machine Type
• Soldering Machine

• Noise Level
• Low

• Operating Temperature
• Ambient

• Operating Type
• Other, Semi-automatic

• Power
• 160w

• Power Rating
• 160w

• Power Source
• Other, AC220V 50/60Hz

• Pressure
• 0.4-0.6Mpa

• Product Type
• Other, Semi-automatic Soldering Machine

• Technology
• Other, Semi-automatic

• Usage & Applications
• PCB Assembly Line, plug product line, electronic product line

• Voltage
• 220v

• Weight (kg)
• 20
